40ft container 3 axles semi-trailer
LOWBED SEMI-TRAILER SPECIFICATION Dimension 13000×3000m×1700mm The rated load 50T Bottom Platform 4 mm Checkered Thick
Contact Now
Product details
| LOWBED SEMI-TRAILER SPECIFICATION | |
|---|---|
| Dimension | 13000×3000m×1700mm |
| The rated load | 50T |
| Bottom Platform | 4 mm Checkered Thickness |
| Main beam | Welding design “I” 300mm side beam , Main beam height 500mm |
| Frame beam | Top Flange 20mm; Bottom Flange 20mm, Middle Flange 10mm; |
| Ramp | Mechanical ladder |
| Axle | 3 axles , 13T FD brand 16ton brake pads |
| Landing Gear | 28T lifting capacity with two speed |
| King Pin | 2.00 or 3.5 inch bolt-in king pin |
| Suspension | Mechanical suspension reforced type |
| Leaf spring | 90mm(W)*16mm(T)*10 Layer , reforced type |
| Tyre | 11.00R20 * 12 pcs |
| Accessories | One standard tool box |
| Spare tire rack | One unit |
| Electrical system | 24 volt electrical system.7 pin electrical connector. Parking .stop,reverse,number plate and indicator lights. rear lights , rear front and side reflectors |
| Color & LOGO | By customer’s requirement |
| Shipping Terms | By Bulk Cargo / RORO |
