Fence Cargo Trailer for Sale
FENCE SEMI TRAILER SPECIFICATION Manufacturer FUDENF Payload 60,000kg Tare weight 73,000kg Dimension
Contact Now
Product details
| FENCE SEMI TRAILER SPECIFICATION | |
|---|---|
| Manufacturer | FUDENF |
| Payload | 60,000kg |
| Tare weight | 73,000kg |
| Dimension | 13000x2500x1550mm (with removable fence 2200mm) |
| Wheelbase | 1310mm |
| Main beam | Beam height 500mm, upper plate 14mm, bottom plate double 8mm, middle plate 16mm, made of Q345 steel |
| Cross/side beam | Q235, channel steel |
| Floor | 3mm diamond steel plate |
| Painting | Complete chassis sandblasting to clean rust, coat of anti-corrosive primer, 2 coats of final paints |
| Tool box | 1 piece |
| Axle | 4 x 16ton FUWA Axle |
| Suspension | Mechanical suspension |
| Leaf spring | 90(W)mm*16(thickness)mm*10 layers |
| Tyre | 12R22.5, 16pcs, Triangle tire Rim 9.0-22.5 |
| Kingpin | JOST King Pin bolt-in type 50mm |
| Landing gear | Double speed, external 28 tons |
| Brake system | WABCO valve dual-line braking system |
| Electrical system | 1 voltage 24V, 2 receptacle: 7 ways (7 wire harness), tail lamp with turn signal, brake light & reflectors, side lamp etc. One set 6-core standard cable. |
